Heavy Duty 1500 KG 3 Phase Rolling Shutter Motor for Industrial & Commercial Doors
The EUROMATIC Rolling Shutter Motor AC 1500 KG 3 Phase is a heavy-duty industrial motor engineered for large rolling shutter doors. Designed for demanding commercial and industrial applications, it delivers powerful lifting performance, smooth operation and long-lasting reliability.
Manufactured with premium-quality components and advanced technology, this motor features overload protection, thermal protection, an anti-fall safety mechanism and an adjustable precision limit switch for safe daily operation. It is suitable for warehouses, factories, logistics centres, shopping malls and other heavy-duty roller shutter installations throughout the UAE.
Applications
- Industrial warehouses
- Factories
- Shopping malls
- Commercial buildings
- Distribution centres
- Retail outlets
- Loading bays
- Large garages
- Storage facilities
Key Features
- 1500 KG maximum lifting capacity
- Heavy-duty 3 phase AC motor
- Smooth and reliable operation
- Overheat protection
- Overload protection
- Anti-fall safety device
- Precision adjustable limit switch
- Manual emergency chain operation during power failure
- Low noise performance
- Easy installation and adjustment
- Minimal maintenance
- Long service life
Technical Specifications
| Model | EU-RSM1500-3P |
| Motor Type | AC Rolling Shutter Motor (3 Phase) |
| Rated Voltage | 220V AC / 50Hz* |
| Input Power | 1250 W |
| Rated Current | 3.8 A |
| Rated Output Torque | 1617 N.m |
| Maximum Lifting Capacity | 1500 KG |
| Rated Output Speed | 5.2 RPM |
| Maximum Lifting Height | 8 m |
| Continuous Working Time | 15 Minutes |
| Operating Temperature | -20°C to +50°C |
*Note: If this model is supplied as a true 3-phase motor, the operating voltage is commonly 380V–415V AC, 50Hz. Please verify the motor nameplate before publishing, as the specification provided lists 220V while the product is described as a 3-phase model.
Package Includes
- 1 × EUROMATIC Rolling Shutter Motor AC 1500 KG 3 Phase
- 1 × Mounting Bracket Set
- 1 × Manual Release Chain
- 1 × Installation Accessories
- 1 × User Manual
Why Choose EUROMATIC?
EUROMATIC rolling shutter motors are built for continuous operation in demanding environments. They combine powerful lifting capacity, advanced safety features and reliable performance, making them an excellent solution for commercial and industrial roller shutter systems across the UAE.
