EUROMATIC Roll Up Shutter Motor 550N 24V DC UAE
Need help choosing the right product?
Share your door type, size and application with our team for a suitable product recommendation and quotation.
Automatic Roller Shutter Door Operator with Soft Start & Soft Stop
The EUROMATIC Roll Up Shutter Motor is an intelligent automatic roller shutter door operator designed for smooth and reliable operation of compatible roll-up shutter doors. Powered by a 24V DC motor, the operator delivers a maximum tensile force of 550N and is suitable for compatible shutter doors with an opening area of up to 15m².
The operator features built-in soft start and soft stop technology for smoother opening and closing while reducing mechanical impact on the shutter system. Its low-noise DC motor makes it suitable for commercial, residential, garage and other automatic roll-up door applications.
An integrated LED display menu makes programming and adjustment easier, while the operating force can be adjusted according to the installation requirements. The installation direction can also be selected for greater flexibility during setup.
Key Features
- Automatic roll up shutter door operator.
- 24V DC motor technology.
- Maximum tensile force of 550N.
- Suitable for compatible door opening areas below 15m².
- Built-in soft start.
- Built-in soft stop.
- Smooth opening and closing operation.
- Low-noise motor operation.
- Selectable installation direction.
- LED display programming menu.
- Easy parameter adjustment.
- Adjustable operating force.
- 100W rated power.
- Low standby power consumption below 7W.
- Operating temperature from -25°C to +50°C.
- Compact 5.2 KG operator.
- 35mm aperture.
- Suitable for residential and commercial shutter automation.
Technical Specifications
| Brand | EUROMATIC |
| Model | EU-RU-550 |
| Product Type | Roll Up / Roller Shutter Door Operator |
| Power Supply | AC 220–240V, 50/60Hz |
| Motor Voltage | 24V DC |
| Rated Power | 100W |
| Maximum Tensile Force | 550N |
| Maximum Door Opening Area | <15m² |
| Ambient Temperature | -25°C to +50°C |
| Standby Power | <7W |
| Weight | 5.2 KG |
| Aperture | 35mm |
| Soft Start | Yes |
| Soft Stop | Yes |
| Installation Direction | Selectable |
| Display | LED Display Menu |
| Operating Force | Adjustable |
| Operation | Low Noise |
550N Maximum Tensile Force
The EUROMATIC Roll Up Shutter Motor provides a maximum tensile force of 550N, delivering reliable opening and closing performance for compatible roller shutter door systems.
Suitable for Shutter Doors Up to 15m²
The operator is designed for compatible roll-up shutter doors with a maximum opening area of less than 15 square metres. Correct motor selection should also consider the shutter construction, weight, balance and mechanical condition.
24V DC Motor with 100W Power
The operator uses a 24V DC motor rated at 100W and is powered from an AC 220–240V 50/60Hz supply. The DC motor system provides smooth, controlled and low-noise automatic shutter operation.
Soft Start & Soft Stop
Built-in soft start and soft stop functions provide smoother acceleration and deceleration during shutter movement. This helps reduce sudden mechanical impact when the door begins moving or reaches its opening and closing positions.
Low-Noise Operation
The EUROMATIC roller shutter door operator is designed for low-noise operation, making it suitable for applications where smooth and quieter automatic door movement is preferred.
LED Display for Easy Programming
An integrated LED display menu simplifies setup and parameter adjustment. Installers can conveniently configure supported operating settings directly from the motor control system.
Adjustable Operating Force
The operating force can be adjusted according to the requirements of the compatible shutter door. Correct force adjustment helps provide smooth and controlled opening and closing performance.
Selectable Installation Direction
The installation direction can be selected according to the shutter configuration, providing greater flexibility during installation and setup.
Low Standby Power Consumption
With standby power consumption of less than 7W, the operator is designed to maintain low electrical consumption while waiting for an opening or closing command.
Applications
- Roll Up Shutter Doors
- Automatic Roller Shutters
- Commercial Shop Shutters
- Garage Roll Up Doors
- Warehouse Roller Shutters
- Workshop Shutters
- Storage Facility Doors
- Commercial Building Shutters
- Residential Roller Shutters
- Automatic Roll Up Doors
Why Choose EUROMATIC Roll Up Shutter Motor?
The EUROMATIC Roll Up Shutter Motor 550N combines a 24V DC motor, 100W rated power, 550N maximum tensile force, soft start and soft stop, LED programming display and adjustable operating force. Suitable for compatible shutter openings below 15m², it provides a smooth, quiet and intelligent automation solution for roll-up and roller shutter doors throughout the UAE.
